MODEL:HPSL-50 Single Output Switching Power Supply |
Features£º
Universal AC input/ full range
Protections: Short circuit/ Over load/ Over voltage
Cooling by free air convection
Small size
Built-in remote control
LED indicator
100% full load burn-in test
height£º23mm
1 year warranty
Dimensions£º195*55*23mm(L*W*H) |
 | |
|
MODEL |
HPSL-50-3.3 |
HPSL-50-5 |
HPSL-50-12 |
HPSL-50-15 |
HPSL-50-24 |
HPSL-50-48 |
| OUTPUT |
DC Voltage |
3.3V |
5V |
12V |
15V |
24V |
48V |
| Rated Current |
10A |
10A |
4.2A |
3.4A |
2.1A |
1.1A |
| Current Range |
0¡«12A |
0¡«12A |
0¡«5A |
0¡«4.1A |
0¡«2.5A |
0¡«1.3A |
| Rated Power |
33W |
50W |
50.4W |
51W |
50.4W |
52.8W |
| Maxium Load at 10 sec. |
39.6W |
60W |
60W |
61.5W |
60W |
62.4W |
| Ripple & Noise |
50mVp-p |
50mVp-p |
80mVp-p |
80mVp-p |
80mVp-p |
100mVp-p |
| DC Adjustment Range |
3¡«3.6V |
4.5¡«5.5V |
10.8¡«13.2V |
13.5¡«16.5V |
21.6¡«27.2V |
43.2¡«52.8V |
| Voltage Tolerance |
¡À3.0% |
¡À3.0% |
¡À2.0% |
¡À2.0% |
¡À1.0% |
¡À1.0% |
| Line adjusting rate |
¡À1.0% |
¡À1.0% |
¡À1.0% |
¡À1.0% |
¡À1.0% |
¡À1.0% |
| Load adjusting rate |
¡À3.0% |
¡À3.0% |
¡À2.0% |
¡À2.0% |
¡À1.0% |
¡À1.0% |
| Setup, Rise Time |
100ms/230VAC 12ms/115VAC£¨ at full load£© |
| Hold Time(Typ.) |
70ms/230VAC 12ms/115VAC at full load |
| INPUT |
DC Voltage |
90¡«264VAC or 127¡«370VDC |
| Frequency |
47¡«63Hz |
| Efficiency(Typ.) |
75% |
81% |
82% |
84% |
85% |
86% |
| Current Range(Typ.) |
115VAC |
0.9A |
1.2A |
| 230VAC |
0.6A |
0.8A |
| Inrush Current Typ. |
Cold start £º 18A/115VAC 35A/230VAC |
| Leakage Current |
<1mA/240VAC |
| PROTECTION |
Over Load |
122%¡«160% |
| Protection type£ºcurrent limiting£¬recovers automatically after fault condition is removed. |
| Over voltage |
3.8¡«4.45V |
5.75¡«6.75V |
13.8¡«16.2V |
17.25¡«20.25V |
27.6¡«32.4V |
57.6¡«67.2V |
| Protection type: hiccup mode, recovers automatically after fault condition is removed. |
| Function |
Remote control on-off |
RC+/RC-:0¡«0.8V set up;4¡«10V shut down |
| ENVIRONMENT |
Working Temp |
-20¡«+70¡æ(see load derating curve) |
| Working Humidity |
20¡«90% RH no co |
| Storage Temp., Humidity |
-20¡«+85¡æ, 10 ¡«95% RH |
| Temp. range |
¡À0.04%/¡æ (0¡«50¡æ) |
| Vibration |
10¡«500Hz£¬2G 10min./1cycle, period for 60min, each along X, Y, Z axes |
| Safety & EMC |
Safety Standards |
Design refer to UL60950-1,TUV EN60950-1 |
| Withstand Voltage |
I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
| Isolation Resisitance |
I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC |
| EMC |
Design refer to EN655022 (CISPR22) Class B |
| Harmonic Current |
Design refer to EN61000-3-2,-3 |
| ESA |
Design refer to EN61000-4-2,3,4,5,6,8,11;ENV50204,EN55024, EN61000-6-2(EN50082-2),heavy industrial class-A standard. |
| OTHERS |
Weight |
0.24kg |
| Packing |
48pcs/12.kg/0.84CUFT |
| NOTE |
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25¡æ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12¡åtwisted pair-wire terminated with a 0.1¦Ì & 47¦Ì parallel capacitor.
3.Tolerance: includes set up tolerance, line regulation and load regulation.
4.Within 30 minites, the peak value proportion is 33.3%, average rated power can not exceed rated power.
5.The power supply is considered as a component inside the equipment, the final equipment must be confirmed it meets EMC directives. |
