MODEL:HS-100 Single Output Switching Power Supply

MODEL

HS-100-5

OUTPUT

DC Voltage

3V

5V

7.5V

12V

15V

18V

24V

27V

48V

Voltage Tolerance

±2%

±2%

±1%

±1%

±1%

±1%

±1%

±1%

±1%

Rated Current

20A

20A

13.6A

8.5A

6.7A

5.6A

4.5A

3.7A

2A

Current Range

0-20A

0-20A

0-13.6A

0-8.5A

0-6.7A

0-5.6A

0-4.5A

0-3.7A

0-2A

Rated Power

60W

100W

102W

102W

100.5W

100.8W

108W

99.9W

96W

Ripple & Noise

100mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

100mVp-p

150mVp-p

DC Adjustment Range

-5%，+10%

-5%，+10%

±10%

±10%

±10%

-4%，+18%

±10%

Setup, Rise, Hold Time

200ms,80ms,20ms at full load

INPUT

Voltage Range

85～132 VAC/180～264VAC 47～63 Hz；Selected by switch 255～370VDC

AC Current

2.4A/115 V 1.2A/ 230 V

Efficiency

70%

78%

80%

81%

81%

82%

84%

84%

84%

Inrush Current

Cold start 30A/115V 60A/230V

Leakage Current

＜1 mA/240VAC

PROTECTION

Over Load

115%～165%

Protection type: Shut down o/p voltage, re-power on to recover

ENVIRONMENT

Working Temp., Humidity

-10℃～+60℃；20%～90 %RH

Storage Temp., Humidity

-20℃～+85℃；10%～95 %RH

Vibration

10～500Hz，2G 10min./1cycle, period for 60min, each along X, Y, Z axes

SAFETY

Withstand Voltage

I/P-O/P:1.5KVAC I/P-O/P:1.5KVAC O/P-FG: 0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD

Safety Standard

Design refer to UL1012

EMC Standard

Design refer to FCC Part15 J Conduction Class B

OTHERS

Weight

0.62Kg

Packing

30pcs/19Kg/1.22CUFT

NOTE

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12″twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor.
3. Tolerance: includes set up tolerance, line regulation and load regulation.
