MODEL:HS-25 Single Output Switching Power Supply

MODEL

HS-25-5

HS-25-12

HS-25-15

HS-25-24

OUTPUT

DC Voltage

5V

12V

15V

24V

Voltage Tolerance

±2%

±1%

±1%

±1%

Rated Current

5A

2.1A

1.7A

1.1A

Current Range

0-5A

0-2.1A

0-1.7A

0-1.1A

Rated Power

25W

25.2W

25.5W

26.4W

Ripple & Noise

50mVp-p

100mVp-p

100mVp-p

100mVp-p

DC Adjustment Range

+10,-5%

±10%

±10%

±10%

Setup, Rise, Hold Time

800ms,50ms,10ms/115VAC 300ms,50ms,80ms/230VAC at full load

INPUT

Voltage Range

85～264 VAC 47～ 63 Hz；120～370VDC

AC Current

0.6 A/115 V 0.35A/ 230 V

Efficiency

72%/115VAC

76%/115VAC

77%/115VAC

80%/115VAC

Inrush Current

Cold start 15A/115V 30A/230V

Leakage Current

＜0.75 mA/240VAC

PROTECTION

Over Load

110%～160%

Protection: Shut down o/p voltage, re-power on to recover

Over Voltage

115%～135%

Protection: Hiccup mode, recovers automatically after fault condition is removed

ENVIRONMENT

Working Temp., Humidity

-10℃～+60℃；20%～90 %RH

Storage Temp., Humidity

-20℃～+85℃；10%～95 %RH

Vibration

10～500Hz，2G 10min./1cycle, period for 60min, each along X, Y, Z axes

SAFETY

Withstand Voltage

I/P-O/P:3KVAC I/P-O/P:1.5KVAC O/P-FG: 0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC

STANDARD

Safety Standard

Design refer to UL1012, TUV EN60950

EMC Standard

Design refer to EN55022，EN61000-3-2，-3，EN61000-4-2，3，4，5；ENV50204，EN55024

OTHERS

Weight

0.28Kg

Packing

45pcs/13.2Kg/0.99CUFT

NOTE
